Dynamic, crash-proof AI orchestration

import os

import flytekit
import pandas as pd
from flytekit import Resources, kwtypes, task, workflow
from flytekit.types.file import CSVFile, FlyteFile
from flytekitplugins.sqlalchemy import SQLAlchemyConfig, SQLAlchemyTask

DATABASE_URI = (
    "postgresql://reader:NWDMCE5xdipIjRrp@hh-pgsql-public.ebi.ac.uk:5432/pfmegrnargs"
)

extract_task = SQLAlchemyTask(
    "extract_rna",
    query_template="""select len as sequence_length, timestamp from rna where len >= {{ .inputs.min_length }} and len <= {{ .inputs.max_length }} limit {{ .inputs.limit }}""",
    inputs=kwtypes(min_length=int, max_length=int, limit=int),
    output_schema_type=pd.DataFrame,
    task_config=SQLAlchemyConfig(uri=DATABASE_URI),
)


@task(requests=Resources(mem="700Mi"))
def transform(df: pd.DataFrame) -> pd.DataFrame:
    """Add date and time columns; drop timestamp column."""
    timestamp = pd.to_datetime(df["timestamp"])
    df["date"] = timestamp.dt.date
    df["time"] = timestamp.dt.time
    df.drop("timestamp", axis=1, inplace=True)
    return df


@task(requests=Resources(mem="700Mi"))
def load(df: pd.DataFrame) -> CSVFile:
    """Load the dataframe to a csv file."""
    csv_file = os.path.join(flytekit.current_context().working_directory, "rna_df.csv")
    df.to_csv(csv_file)
    return FlyteFile(path=csv_file)


@workflow
def etl_workflow(
    min_length: int = 50, max_length: int = 200, limit: int = 10
) -> CSVFile:
    """Build an extract, transform and load pipeline."""
    return load(
        df=transform(
            df=extract_task(min_length=min_length, max_length=max_length, limit=limit)
        )
    )

import pandas as pd
import plotly
import plotly.graph_objects as go
import pycountry
from flytekit import Deck, task, workflow, Resources


@task(requests=Resources(mem="1Gi"))
def clean_data() -> pd.DataFrame:
    """Clean the dataset."""
    df = pd.read_csv("https://covid.ourworldindata.org/data/owid-covid-data.csv")
    filled_df = (
        df.sort_values(["people_vaccinated"], ascending=False)
        .groupby("location")
        .first()
        .reset_index()
    )[["location", "people_vaccinated", "date"]]
    filled_df = filled_df.dropna()
    countries = [country.name for country in list(pycountry.countries)]
    country_df = filled_df[filled_df["location"].isin(countries)]
    return country_df


@task(disable_deck=False)
def plot(df: pd.DataFrame):
    """Render a Choropleth map."""
    df["text"] = df["location"] + "<br>" + "Last updated on: " + df["date"]
    fig = go.Figure(
        data=go.Choropleth(
            locations=df["location"],
            z=df["people_vaccinated"].astype(float),
            text=df["text"],
            locationmode="country names",
            colorscale="Blues",
            autocolorscale=False,
            reversescale=True,
            colorbar_title="Population",
            marker_line_color="darkgray",
            marker_line_width=0.5,
        )
    )

    fig.update_layout(
        title_text="Share of people who recieved at least one dose of COVID-19 vaccine",
        geo_scope="world",
        geo=dict(
            showframe=False, showcoastlines=False, projection_type="equirectangular"
        ),
    )
    Deck("Bar Plot", plotly.io.to_html(fig))


@workflow
def analytics_workflow():
    """Prepare a data analytics workflow."""
    plot(df=clean_data())
